Designed for motorhomes, campervans, and commercial RVs, the ACTECmax AC.132.033 is engineered to provide reliable and efficient climate control in any season. Whether it’s the scorching heat of summer or the chill of winter, this advanced RV AC unit ensures a comfortable cabin environment with a cooling capacity of 10,000–15,000 BTU and a heating capacity of 12,000–16,000 BTU.
Perfect for B2B Clients and Bulk Procurement
Ideal for OEMs, RV dealers, and large-scale operations, the ACTECmax RV AC unit is available in bulk packaging tailored to fit 20GP, 40GP, and 40HQ containers. Its modular and customizable features ensure smooth integration into various RV models.
| Specification | Details |
|---|---|
| Model | AC.132.033 RV AC Unit |
| Type | Full DC Inverter |
| Power Supply | AC 115V |
| Rated Cooling Capacity | 10,000–15,000 BTU |
| Rated Heating Capacity | 12,000–16,000 BTU |
| Power Consumption (Cooling/Heating) | 1000–1650 W / 1000–1400 W |
| Current (Cooling/Heating) | 8.7–14.0 A / 8.7–12.2 A |
| EER / COP | 1.8–2.0 / 2.3–2.5 |
| Refrigerant | R32 (16/11.3 oz) |
| Compressor | GMCC Horizontal type, high-efficiency, reliable |
| Airflow (High Speed) | 650 m³/h (28,251 ft³/h) |
| Indoor Noise Level (L/M/H) | 56 / 59 / 62 dB(A) |
| Outdoor Noise Level (L/M/H) | 59 / 62 / 65 dB(A) |
| Net Weight (Rooftop) | 44 kg |
| Gross Weight (Rooftop) | 46 kg |
| Net Dimensions (Rooftop) | 1069 × 769 × 240 mm |
| Packing Dimensions (Rooftop) | 1137 × 844 × 488 mm |
| Ceiling Opening Dimension | 400 × 400 mm (362 × 362 mm optional) |
| Controller | Remote Controller (optional) |
| Fan Type | Brushless DC Motor |
| Evaporator | Finned Evaporator |
| Condenser | Finned Condenser |
| Housing Material | ABS |
| Color | Standard White, customizable |
| Wholesale Packing (Units per Container) | 20GP: 72 units40GP: 168 units40HQ: 168 units |
